4.4. Technical data
4.4.1. Joystick VCS0
Ambient temperature - 20°C to +60°C
Rated operating voltage (Ue in V) 250
Rated operating current (Ie) in A
AC12 (ohmic load) 50Hz – 60Hz 10
AC15 (inductive load) 50Hz – 60Hz 4
DC12 (ohmic load) 12V 4
24V – 42V 1.7
115V – 230V 0.3
DC13 (inductive load) 24V – 42V 0.8
115V – 230V 0.2
Short-circuit rating Circuit breaker 6
Fuse 6
Mechanical service life in million switching cycles 10
Connections
Normal clamp with pan head screw M 3.5
Wire cross-section, stranded with ferrule 1.5mm
2
4.4.2. Fittings in knob G41
Ambient temperature - 20°C to +60°C
Rated operating voltage (Ue in V) 250
Rated operating current (Ie) in A
AC12 (ohmic load) 50Hz – 60Hz 4
AC15 (inductive load) 50Hz – 60Hz 3
DC12 (ohmic load) 12V 2
24V – 42V 1.6
115V – 230V 0.3
DC13 (inductive load) 24V – 42V 1.1
115V – 230V 0.2
Connections
Normal clamp with pan head screw M 3.5
