9.2.3. Joystick VCS0 S1…
Note
The following installation instructions apply to the joystickVCS0 S1:
See also section 4.1 "Type codes", page 56.For installation instructions for other variants,
contact
Spohn & Burkhardt GmbH & Co. KG (for contact data see Imprint, page 2).
Figure 20.
6
3
21
21
6
max. 2max. 2
max. 2
96
Joystick VCS0 S1… – removal
1. Carefully pull the rubber boot (3) o the boot holder escutcheon (21)
2. Undo the screws.
3. Open the installation space and pull the joystick VCS0 out of the installation space from below.
10. Disposal
The device is to be disposed of as per the national and international laws and regulations.
11. Reference documents
Conformity Declaration of conformity
Variants Product data sheet VCS0
You will receive the related documentation for bespoke versions.
