Spohn & Burkhardt VCS0 - Joystick VCS0 Drive

59
Spohn + Burkhardt
4.4.3. Joystick VCS0 drive
Note
Pay attention to the direction of viewing for the following knobs: G1, G13, UGN, UGA
Note
If there is no information about the version, layout U is supplied.
Figure 3.
X
UN
Y
- AK VVCS0 -
Blickrichtung
Viewing direction
Y
X
U
N
Blickrichtung
Viewing direction
X
UN
Y
- AK EVCS0 -
Y
U
X
N
Antrieb/Drive E
Anordnung/Layout: N U Y X
Anbaurichtung Potentiometer/Geber
Mounting direction potentiometer/encoder
Antrieb/Drive V
Anordnung/Layout: N U Y X
Joystick VCS0 … – drive
