Square QED-2 - Section 10-Switchboard Insulation Resistance Chart

Section 10—Switchboard Insulation Resistance Chart Power-Style™ QED-2 Switchboards
53© 1988–2018 Schneider Electric All Rights Reserved80043-055-13
ENGLISH
Section 10—Switchboard Insulation Resistance Chart
Always use a 500 or 1,000 Vdc megohmmeter when testing insulation resistance.
NOTE: The Neutral–Ground column is provided to record the results of the
pre-energizing checkout procedure only.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Turn off all power to the switchboard before testing.
• Always use a properly rated voltage sensing device to confirm power is off.
Failure to follow these instructions will result in death or serious injury.
CAUTION
HAZARD OF OVERVOLTAGE TO CONTROL AND PROTECTION COMPONENTS
• Remove the long-time rating plug before electrical insulation testing a circuit
breaker that has a label stating “Warning: Disconnect Plug Before Dielectric
Test.”
• For Masterpact™ MTZ circuit breakers, remove the voltage power supply
(VPS) module if it is present.
• Some Micrologic™ trip units are not rated for voltages that would occur during
electrical resistance insulation testing.
• Open all control and metering disconnects from the control circuits.
Failure to follow these instructions can result in injury or equipment damage.
Date
Phase–Phase Phase–Ground Neutral–Ground
All Disconnects Open
a-b b-c c-a a-ground b-ground c-ground Neutral–Ground
Date
All Disconnects Closed
a-b b-c c-a a-ground b-ground c-ground Neutral–Ground
