8.11.1 Audio line output (green jack) connector
A 3.5 mm stereo audio green jack output CN5 is available to support the headphone (see
Figure 22).
8.11.2 Audio line input (blue jack) connector
A 3.5 mm stereo audio blue jack input CN4 is available to support the audio line input (see
Figure 22).
Table 15. Audio line output connector CN5
Pin number Description
3GND
4 Right
6Left
Table 16. Audio line input connector CN4
Pin number Description
3GND
4 Right
6Left
