UM2469 Rev 1 33/59
UM2469 STM32F7308-DK Discovery board I/O assignment
58
Appendix A STM32F7308-DK Discovery board I/O
assignment
Table 17. I/O assignment
Pin
number
Pin Function Label
A1 PE3 GPIO_Output ARD_D7_GPIO
A2 PE2 QUADSPI_BK1_IO2 -
A3 PE1 FMC_NBL1 -
A4 PE0 FMC_NBL0 -
A5 PB8 I2C1_SCL -
A6 PB5 SPI1_MOSI ARD_D11_TIM3_CH2_SPI1_MOSI
A7 PG14 GPIO_Output WIFI_RST
A8 PG13 GPIO_Output WIFI_GPIO_0
A9 PB4 SPI1_MISO ARD_D12_SPI1_MISO
A10 PB3 SYS_JTDO-SWO -
A11 PD7 FMC_NE1 -
A12 PC12 UART5_TX UART_TXD_WIFI_RX
A13 PA15 TIM2_CH1 STMOD+_TIM2_CH1_2_ETR
A14 PA14 SYS_JTCK-SWCLK -
A15 PA13 SYS_JTMS-SWDIO -
B1 PE4 GPIO_Output ARD_D8_GPIO
B2 PE5 TIM9_CH1 ARD_D3_TIM9_CH1
B3 PE6 TIM9_CH2 ARD_D6_TIM9_CH2
B4 PB9 I2C1_SDA -
B5 PB7 FMC_NL -
B6 PB6 QUADSPI_BK1_NCS -
B7 PG15 GPIO_EXTI15 SAI2_INT
B8 PG12 GPIO_Output PMOD_GPIO_0
B10 PG10 SAI2_SD_B -
B11 PD6 GPIO_Output WIFI_GPIO_2
B12 PD0 FMC_D2 -
B13 PC11 GPIO_Output STMOD+_UART4_RXD_s
B14 PC10 QUADSPI_BK1_IO1 -
B15 PA12 USB_OTG_FS_DP -
C2 PI7 SAI2_FS_A -
C3 PI6 SAI2_SD_A -
