Operational amplifiers (OPAMP) RM0440

824/2126 RM0440 Rev 4

25.5.11 OPAMP5 timer controlled mode register (OPAMPx_TCMR) (x = 1...6)

Address offset: 0x28

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

LOCK Res.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Res.

T20CM

_EN

T8CM_

T1CM_

VPS_SEL

VMS_

SEL

rw rw rw rw rw rw

Bit 31 LOCK: OPAMP5_TCMR lock

This bit is write-once. It is set by software. It can only be cleared by a system reset.

This bit is used to configure the OPAMP5_TCMR register as read-only.

0: OPAMP5_TCMR is read-write

1: OPAMP5_TCMR is read-only

Bits 30:6 Reserved, must be kept at reset value.

Bit 5 T20CM_EN: TIM20 controlled mux mode enable

This bit is set and cleared by software. It is used to control automatically the switch between the

default selection (VP_SEL and VM_SEL) and the secondary selection (VPS_SEL and

VMS_SEL) of the inverting and non inverting inputs. This automatic switch is triggered by the

TIM20 CC6 output arriving on the OPAMP5 input multiplexers.

0: Automatic switch is disabled.

1: Automatic switch is enabled.

Bit 4 T8CM_EN: TIM8 controlled mux mode enable

This bit is set and cleared by software. It is used to control automatically the switch between the

default selection (VP_SEL and VM_SEL) and the secondary selection (VPS_SEL and

VMS_SEL) of the inverting and non inverting inputs. This automatic switch is triggered by the

TIM8 CC6 output arriving on the OPAMP5 input multiplexers.

0: Automatic switch is disabled.

1: Automatic switch is enabled.
