ST700 Dash Display System Operation
© Stack
35
Press the Driver button to return to Layer 1 and the beginning of the se-
quence.
Pop–up Display Layers
The ST700 Dash Display System can supply information to the driver
through several pop–up messages and alarms on the display as shown
in Figure 13. The pop–up messages remain on display for a short, user–
defined period. The alarms remain on display until the alarm condition
disappears or until the driver cancels them.
You may set the time in seconds that the display shows each pop–up
message from zero (meaning that pop–up messages never appear) to 99
seconds (meaning that the pop–up remains on display permanently).
Refer to page 49 for instructions. When a pop–up message appears,
three conditions will cancel it:
1. The pop–up message ‘times out’ at the end of its user–defined pre–
set display period.
2. The ST700 Dash Display System overwrites an existing pop–up
message with a new one that occurs before the ‘time out’ period
elapses for the old message.
3. The driver presses the Driver button to cancel the pop–up message
and return to the normal driver display.
It is important to distinguish between pop–up messages and alarm
messages. Alarm messages will remain on display with the Alarm LED
lit until the alarm is cancelled or until the alarm condition disappears.
