STACK ST8100 Display System Chapter 1. Introducing the Display System
Users Guide 1
Chapter 1. Introducing the Display SystemChapter 1. Introducing the Display System
The Stack ST8100 Display System monitors and displays a range of
values, known as performance parameters, needed for effective car and
driver management in most competitive situations.
The system combines an analog tachometer with a digital display for the
following performance parameters:
1. Engine speed (RPM)
2. Oil pressure
3. Oil temperature
4. Water temperature
5. Fuel pressure
6. Battery Voltage
7. Wheel speed (optional)
8. Lap times (optional)
9. Lateral Acceleration (optional). This option is used only in conjunction
with the optional logging system. The information from it is not
displayed on the Display Module.
10. Maximum and minimum corner speeds display(optional)
You can view the peak values (tell-tales) for all the parameters.
The system provides a range of warning messages based on preset alarm
values for the following performance parameters:
1. Oil pressure
2. Oil temperature
3. Fuel pressure
4. Water temperature
5. Battery voltage
You can enable or disable the warning system for each parameter
individually.
