STACK ST8100 Display System Chapter 4. Configuring the Display System
Users Guide 17
Chapter 4. Configuring the Display SystemChapter 4. Configuring the Display System
Configuration modeConfiguration mode
You put the Display System into configuration mode by pressing
Switches 1 and 2 together. You then work through the configurable
parameters in a preset sequence. Press Switch 3 to display the next
configurable parameter. The configurable parameters are displayed in
the following order:
Configurable
Parameter
Setting Required
Wheel
Circumference
Set a value in the units of measurement
indicated.
Wheel sensor
pulses per
revolution (W.S.
PULSES/REV)
Set the value to the number of ferrous targets
that the wheel sensor is to count for each wheel
revolution.
Engine Speed
(Cylinders)
Number of cylinders in engine (for RPM)
GATE RPM Minimum RPM for the Fuel Pressure, Oil
Temperature and Pressure, and Water
Temperature warnings to operate.
Logging RPM RPM at which the logging option is started.
SHIFT RPM RPM at which gear shift light is to come on
HIGH WATER Maximum water temperature alarm
HIGH OIL T Maximum oil temperature alarm
LOW FUEL P Minimum fuel pressure alarm
LOW OIL P Minimum oil pressure alarm
LOW BATT Minimum battery voltage alarm
