STACK ST8100 Display System Chapter 2. Getting Started
Users Guide 3
Chapter 2. Getting StartedChapter 2. Getting Started
This chapter guides you through the initial unpacking and setting up of
the equipment for pre-installation checks and familiarization with its
operation.
Standard ST8100 Display System ItemsStandard ST8100 Display System Items
The ST8100 Display System is supplied with the following standard
components:
Quantity Description
1 Display Module (ST86x ) with 2 mounting brackets
1 Wiring Harness (ST872 )
2 Pressure Sensors (ST744, ST745, ST746)
2
Temperature Sensors (ST760, ST761, ST762, ST763, ST764)
4 Switches (supplied with and to be connected to the wiring
harness)
Optional ST8100 Display System ItemsOptional ST8100 Display System Items
The ST8100 Display System can be used with the following optional
components:
Quantity Description
1 RPM Sensor (ST696 Opto Isolator or ST697 H.T. Pick-up)
1 Wheel Speed Sensor (ST670)
1 Infra-red Lap Time Receiver (ST543)
1 Infra-red Lap Time Beacon (ST544)
1 External Gear Shift Warning Lamp
1 External Alarm Warning Lamp
1 Corner Speed option. Note: The ST8109 Corner Speed option
is delivered prefitted in the Display Module.
