Error! Main Document Only.Chapter 5. Installing the Display System STACK ST8100 Display System
24 Users Guide
Warning lightsWarning lights
The Display Module has two built-in warning lights. One of these is for
the gear-shift light and the other for warning the driver that an alarm
has been triggered.
As an option, you can install additional external warning lights for these
functions. External warning lights should be installed in any position
that is in the driver’s direct line of vision, as they need to be visible at all
times.
Stack can supply suitable external warning lights for installation in the
dashboard as well as shrouded versions that can be mounted on top of
the dashboard.
ð If you are using your own warning lights, ensure that the
bulb rating does not exceed 2 Watts; otherwise the Display
Module will be damaged.
Engine Speed (RPM)Engine Speed (RPM) Measurement Measurement
The engine speed (RPM) is measured by connecting the engine speed
wire directly to the ignition system. A single wire from the connector
labelled ES, connects the Display System to the ignition system or low-
tension side of the coil.
