Chapter 3. Operating the Display System STACK ST8100 Display System
10 Users Guide
Display Layer 5Display Layer 5
This display is available when the optional Corner Speed feature is
installed.
Display layer 5 shows:
• Current speed (SPEED)
• Maximum speed straight (MAX)
• Actual speed when Switch 1 was last pressed (HOLD)
• Lowest speed attained in the previous corner (MIN)
Press Switch 3 to display layer 1 again.
