IMPORTANT. BLDC controller always use max current and don't use max voltage because main characteristic for
BLDC is max current, max voltage usually more than 8SMC5 supply voltage.
Motion setup - settings related to the movement kinematics
Working speed - movement speed.
Backlash compensation - backlash compensation. Since the stage mechanics are not ideal there is a difference between approaching a
given point from the right and from the left. When the backlash compensation mode is on the stage always approaches the point from
one side. The preset value determines the number of steps which the stage takes to pass a given point in order to come back to it
from the same side. If the specified number is above zero the stage always approaches the point from the right. If it is below zero the
stage always approaches the point from the left.
Backlash compensation speed - speed of backlash compensation. When the backlash compensation mode Backlash compensation is on
the stage approaches the point from the right or from the left with a preset speed determined in the number of steps per second.
Acceleration - enables the motion in acceleration mode, the numerical value of the field is the acceleration of movement.
Deceleration - movement deceleration.
Number of poles - number of poles per revolution
Feedback settings
Encoder - use of encoder as a feedback sensor. The following encoder types are available: Single-ended, Differential or Autodetect.
Encoder counts per turn - this parameter defines the number of encoder pulses per one motor axis full rotation.
