motor;
PWM level the PWM duty factor (only for DC motors);
Temperature is temperature of controller processor;
Joystick is value of input signal from the joystick;
Analog input is value of analog input;
Flags shows the state of the controller flags.
Button functions
Clear - clears the stored data and the Charts window;
Start - starts recording the data and displaying charts. If the option "Break data update when motor stopped" in Program
configuration -> Graph setup -> Common is turned on, no data recording and charts auto-scrolling will occur when the
motor is stopped;
Stop - stops data reading;
Save - stores chart data to a file;
Load - loads chart data from a previously saved file;
Export to CSV - exports chart data to CSV file
