5.5.2. Positioner general characteristics
Stage configuration -> Stage in the Application Settings
Positioner general characteristics window
Stage parameter prouop contains information about the stage.
Manufacturer - the manufacturer name.
Part number - the catalog number.
Lead screw pitch - lead screw pitch.
Units - stage movement measurement units (mm, degrees, steps).
Max. speed - the maximum speed.
Travel range - range of motion.
Supply voltage - acceptable supply voltage range.
Max. current consumption - the maximum current consumption.
Horizontal load capacity - the maximum horizontal load on the stage.
