Star Trac Pro - Installation Instructions (Contd); 6; 7

9
9
Bike, CrossTrainer and Stepper
7
- Slide the top monitor support bracket (Gooseneck)
and lower over neck.
- Secure the gooseneck by inserting the 4 flat head
screws and tighten securely.
-
Use any 4 holes to adjust TV height. See A/V install
section for more info.
Installation Instructions (Cont’d)
Installation Instructions (Cont’d)
Bike, CrossTrainer and Stepper
- Put the crossbow back plate in position and insert
the two socket head cap screws by hand.
- Tighten
the 2 screws into the cross bow using the
9/16” Allen wrench.
6
*Save wire management for A/V install — see A/V section.
