As an A/V Installer, you will be tasked with running the TV power and video to
each unit. You should provide the club owner with a clear definition of your role in
theinstallation process, and what other sub-contractors the club owner will require to
complete the installation.
When installing and wiring TVs on Star Trac brackets, there are several areas you
should be aware of:
Mounting the TV
• The TV will be mounted to the Star Trac bracket using the provided 75mm and
100mm VESA standard mounting plate.
• I n the bracket hardware kit, (4) 4mm x 10 screws are provided to attach the TV
to the bracket.
• The installer is responsible for bringing all the required hardware to mount the
TV.
• It is impossible for Star Trac to provide all possible mounting hardware for
every 3rd party product on the market.
• As an installer, you are required to provide longer or shorter screws due to
variations in TV manufacturer mounting requirements.
• If your A/V solution includes a DVD player or other 3rd party bracket or adapter,
the installer will be required to bring all the needed mounting hardware, and
verify compatibility with our bracket.
• Please request a bracket sample from Star Trac before performing a large
onsite installation as to verify a proper fit of the A/V solution you are supplying.
Adjusting the TV Height
• The bracket gooseneck allows the height of the TV to be adjusted up and down
by selecting a different set of threaded holes in the bracket neck.
•
Typically you will want to lower the TV to a position just above the fitness
equipment display console.
•
Do not lower the TV to the point where it actually touches the fitness equipment
display console.
A/V Installer’s Guide
Bike, CrossTrainer, Stepper and Pro Tread
