Steinbach Active Balls 50 - Hose Connections; Connecting the Pressure Line

5. Connect the base plate
9
to the lter
vessel
6
.
The base plate is connected to the lter
vessel.
Hose connections
- Fasten all aached hose connecons with hose clamps to ensure that the system
does not leak.
We recommend addionally sealing the hose connecons with Teon tape.
- Use suitable pool hoses for the described connecons.
Some hoses, such as the pressure hose, are very s. Place them in the sun
before use so that the heat makes them more exible.
Connecting the pressure line
1. Push or screw one end of the pressure
hose
14
onto the pump outlet
22
.
2. Place a hose clamp
15
over the
pressure hose. Using a Phillips
screwdriver PH1
32
, turn the screw on
the hose clamp clockwise to ghten
the hose clamp over the connecon.
3. Place the second hose clamp over the
pressure hose.
4. Push the end of the pressure hose
onto the pressure line
26
connecon
on the lter cover
1
.
5. Posion the hose clamp on the
connecon and ghten this one as
well with a Phillips screwdriver.
The pressure line
26
is connected.
