12-11
B28 10A Air conditioner
B29 25A
Air conditioner condenser
fan
B30 30A HVAC blower fan
B33 10A Dome light
B34 20A
Automatic transmission
cooling fan
B36 20A Engine drive unit
M1 10A Backup lights
M2 10A Instrument cluster
M3 15A Wipers
M4 10A
Auxiliary power supply
(ignition bus)
M5 10A Relay control
M6 10A Automatic transmission
M8 10A Exhaust brake
M9 5A Engine control unit
M11 10A ABS
S1 10A Starter
*
5A
Spare fuse
10A
15A
20A
30A
5A
Automatic transmission
troubleshooting
(diagnosis)
10A
Automatic transmission
troubleshooting
(memory clear)
5A
ABS troubleshooting
(diagnosis)
10A
ABS troubleshooting
(memory clear)
5A
Engine ECU troubleshoot-
ing (diagnosis)
10A
Engine ECU troubleshoot-
ing (memory clear)
Fuse
No.
Amperage Protected circuit
