8. Wash cycle time ends
A. 1MTR de-energized
1) K6 de-energizes
2) D69 turns off
B. Control checks booster temp (3QTM)
C. If below 180°F wash cycle is extended 120
sec (Sense-A-Temp is optional)
1) Booster reaches 180°F before 120 sec
- wash cycle terminates.
2) End of 120 sec Sense-A-Temp cycle
before booster at 180°F, wash cycle
terminates
D. 2 sec delay to stabilize water for accurate
1PSR reading
E. 1CR energized if temp below 155°F
9. Drain cycle begins - WASH still displays
A. 3MTR energized
1) K4 energizes
2) D77 turns on
B. 1PRS senses 840 mV
C. 3MTR de-energized
1) K4 de-energizes
2) D77 turns off
Rinse Cycle
1. RINSE displayed
2. 2MTR energized for 10 sec
A. K7 energizes
B. D72 turns on
3. 2PRS senses 830 mV from booster
4. 1CON de-energized
5. 2MTR de-energized after 10 sec cycle
A. K7 de-energizes
B. D72 turns off
6. 1SOL energized to refill booster
A. K3 energized
B. D76 turns on
7. 5 sec into fill - READY displayed
8. 2PRS senses 1400 mV
9. 1SOL de-energized
A. K3 de-energized
B. D76 turns off
10. 2HTR cycles on 3QTM at 180°F
11. Unit stays in Ready Mode until a wash cycle is
initiated or power is turned off.
Power Down Sequence
1. Push Power Button
2. DRAIN displayed.
A. 3MTR Drain pump energized
1) K4 energizes
2) D77 turns on
B. Water is pumped from sump.
C. 3MTR Drain pump de-energized
1) K4 de-energizes
2) D77 turns off
3. Water is pumped from booster
A. 2MTR energized for 18 sec
1) K7 energizes
2) D72 turns on
B. 2MTR de-energized
1) K7 de-energizes
2) D72 turns off
4. Drain pump energized for 20 sec
A. 3MTR energized
1) K4 energizes
2) D77 turns on
B. At end of 20 sec - 3MTR de-energized
1) K4 de-energies
2) D77 turns off
5. Dishwasher shuts off.
SG, SU-L, SU-H DISHWASHERS - ELECTRICAL OPERATION
Page 51 of 59 F45577 (1215)
