104 MS 341, MS 361, MS 361 C
Removing screw
No. Part Name Part No. Application Rem.
33 Torque wrench 5910 890 0301 0.5 to 18 Nm
Alternative: Torque wrench
5910 890 0302 with optical/acoustic
signal
34 Torque wrench 5910 890 0311 6 to 80 Nm
Alternative: Torque wrench
5910 890 0312 with optical/acoustic
signal
35 Crimping tool 5910 890 8210 Attaching connectors to electrical wires
36 Socket, 13 mm, DIN 3124 5910 893 5608 Flywheel nut
37 Socket, DIN 3124-S19x12.5L 5910 893 5613 Clutch
38 Screwdriver bit T 27 x 125 0812 542 2104 Removing and installing spline socket
head screws with electric or pneumatic
screwdrivers; tighten down screws with
torque wrench
39 T-handle screwdriver, T 27 x 150 5910 890 2400 IS-P screws (4 mm) 1)
40 Press arbor 1118 893 7200 Removing and installing ball bearing
(clutch side)
41 Press arbor 1122 893 7200 Removing and installing ball bearing
(flywheel side)
42 Pliers, DIN 5254-A 19 0811 611 8380 Removing and installing external
retaining rings
43 Assembly drift 0000 893 4700 Removing and installing the piston pin
44 Press sleeve 1118 893 2400 Installing oil seal(s)
45 Press sleeve 1124 893 2400 Pulling crankcase halves together
Remarks:
1) Use only for releasing P screws.
