6 MS 341, MS 361, MS 361 C
3.5 Tightening Torques
DG screws are used in polymer and light metal components. These screws form a permanent thread when they
are installed for the first time. They can be removed and installed as often as necessary without impairing the
strength of the screwed assembly, providing the specified tightening torque is observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque Remarks
Nm
Screw IS-M4x8 Chain tensioner cover plate/crankcase 3.0
Screw IS-M4x12 Brake band/crankcase 3.0 1)
Screw IS-P4x10 Brake cable retainer/tank housing 1.5 6)
Collar screw IS-M8x21.5 Collar screw for guide bar 23.0 1)
Screw IS-M4x12 Cover, chain brake/crankcase 3.0
IS-M10x1 Decompression valve 14.0
Screw IS-B4.2x9.5 Spark arresting screen/muffler 2.0
Screw IS-M4x12 Generator 3.0 1)5)
Screw IS-P5x16 Front handle/plug, AV spring 4.0
Screw IS-P6x19 Front handle/plug, AV spring 7.0 5)
Screw IS-P6x21.5 Front handle/tank housing, top right 7.0 3)
Screw IS-P6x32.5 Front handle/tank housing, top right 5.0 4)
Screw IS-P6x19 Front handle/tank housing, bottom 7.0 3)
Screw IS-P6x21.5 Front handle/tank housing, bottom 5.0 4)
Screw IS-M5x35 Handschutz/fan housing/crankcase 6.0
Nut M5 Shroud/stud, cylinder 3.0
Screw IS-P6x21.5 Chain catcher/crankcase/bearing plug 6.0
Screw IS-M5x16 Spiked bumper/crankcase 8.0
Screw IS-M5x12 Spiked bumper/crankcase/lock nut 8.0
Screw IS-M5x25 Crankcase, sprocket side/fan side 10.0
Screw IS-M5x16 Bearing plug/cylinder 10.0 2)
Screw IS-M5x20 Fan housing/crankcase 6.0
Carrier M12x1L Carrier/crankshaft 50.0
Remarks:
1) Loctite 243, medium strength
2) Loctite 270, high strength
3) aluminium
4) polymer
5) only version with handle heating
6) only version with QuickStop Super
