Stihl MS 341 Shop Manual

Online version - not for reprint
87MS 341, MS 361, MS 361 C
: Push the manifold flange through
the tank housing intake opening.
VA
212RA072
: Take out the collar screw (1).
– Remove the spring between front
handle and cylinder – b 9.1.1
– Pry the spring and annular buffer
between crankcase and tank
housing out of the crankcase –
VA
212RA186
1
b 9.1.3
– On machines with
QuickStop Super, disconnect the
coasting brake cable from the
brake lever – b 5.5.2
– Carefully separate the crankcase
from the tank housing and swing
it to one side.
: Pull off the hose (1).
– Replace the tank housing –
b 12.10
VA
212RA188
1
– Replace the crankcase – b 6.7
Reassemble in the reverse
sequence.
– Connect impulse hose to tank
housing.
– Impulse hose must not be twisted
or kinked.
: To pull the manifold flange
through the intake opening in the
VA
212RA091
1
tank housing, wind a piece of
string (1) (about 15 cm long)
around the back of the flange.
and pass the ends of the string
through the intake opening.
– Pass the ends of the string
through the intake opening.
– Press the manifold down.
: Pull the ends of string outwards.
Check that flange is properly seated
in the tank housing.
Reassemble all other parts in the
reverse sequence.
VA
212RA092
