R2W PLUS
63
①
Click “CYL.Offset” key.
【 CYL.Offse
t】
②Collimate the center(P1)
of column surface, and then
click “Measure” key.
【Measure】
③Collimate left point(P2) of
column surface, and then
click “Continue” key.
【Continue】
