strapex SMA 30 - Page 49

03.11
Strapex SMA 30
 38 A20-132005 Druckfeder LH&CenterBlockSpring CompressionSpring 2 * 39 A20-132003 Messer CutterLower Couteau 1
 40 G04-210628 Kugellager BallBearing,628ZZ RoulementàBilles,628ZZ 3  41 A20-132004 Feder CutterSpringHook Ressort 1  42 A20-130006 Druckfeder CutterTensionSpring Ressort 1  43 A20-130002 Gewindebolzen CutterTensionSpringHook AttachedeRessort 1  44 A20-131003 Schraube CutterUpperPin VisàTêteCylindr 1
 45 A20-110001 Spannglocke TensionCam CamedeTension 1  46 G04-216205 Kugellager6205ZZ BallBearing,6205ZZ RoulementàBilles,6205ZZ 2  47 W37-070720 Keil,7x7x20(Square) Key,7x7x20(Square) Clavette,7x7x20(Square) 2  48 A20-111006 Kurvenwelle CamShaft Arbre 1  49 A20-111008-1 Distanzring28.8x34x28.3 Collar28.8x34x28.3 Entretoise28.8x34x28.3 1  50 A20-111002 Kurvenscheibe RHPressCam Cames 1  51 A20-111009 Distanzring28.8x34x20 Collar28.8x34x20 Entretoise28.8x34x20 1  52 A20-111015-2 Kurvenscheibe CenterPressCam Cames 1  53 A20-111010 Distanzring28.8x34x8 Collar28.8x34x8 Entretoise28.8x34x8 2  54 A20-111004 Kurvenwelle HeaterCam Cames 1  55 A20-111005 Kurvenwelle LH.PressCam Cames 1  56 A20-111011 Distanzring28.8x34x5.5 Collar28.8x34x5.5 Entretoise28.8x34x5.5 1  57 A20-111001 Kurvenwelle SlideTableCam Cames 1  58 A20-111012 Distanzring28.8x34x14 Collar28.8x34x14 Entretoise28.8x34x14 1  59 A20-111007 Stellring CamShaftCoupling Bague 1  60 A20-120002 Hebelachse SlideTableFrameShaft Arbre 1  61 A20-171201 Rollenstift FeedRollerRouleau Rouleau 1  62 G04-216202 Kugellager6202ZZ BallBearing,6202ZZ RoulementàBilles,6202ZZ 4  63 A20-171006 Riemenscheibe FeedRollerPulley(50/60Hz) Poulie 1  64 G04-210628 Kugellager628ZZ BallBearing,628ZZ RoulementàBilles,628ZZ 1  65 A20-171005-1 Bolzen(Auto-Feed) LeverHolder Goujon(Auto-Load) 1   A20-171005 Bolzen LeverHolder Goujon 1  66 A20-171103-0CAA Rolle(9mm) FeedUpperRoller(9mm) RouleaudePression(9mm) 1   A20-171103-0DAA Rolle(12mm) FeedUpperRoller(12mm) RouleaudePression(12mm) 1   A20-171103-0EAA Rolle(15mm) FeedUpperRoller(15mm) RouleaudePression(15mm) 1  67 A20-171003 Exzenterwelle FeedUpperRollerShaft ArbreExcentrique 1  68 W37-070748 Keil7x7x48(Square) Key7x7x48(Square) Clavette7x7x48(Square) 1  69 W35-070790 Keil7x7x90 Heater&PressCamKey7x7x90 Clavette7x7x90 1  70 A20-161001 Spannarm TensionArm BrasdeTesnion 1  71 A20-165150 Einstellhebel TensionAdjustArm LevierdeJustage 1  72 A20-160001 Welle TensionArmShaft Arbre 1  73 A20-161002 Stift TensionjawShaft Goupille 1  74 A20-161003 Feststellschraube TensionArmSpringHook Goujonleté 1  75 A20-120010 Scheibe EndPlate Rondelle 1 49
 Pos. Artikel-Nr. Benennung Partname Article Stück   Partno    Quantity   Nod'article    Pièce  * EmpfohleneErsatzteile * Recommendedspareparts * Piècesderechangerecom.
Fig.A Verschluss-Einheit Sealingunit Unitédesertissage 
