3 SYSTEM COMPONENTS
This chapter describes the components of the Origin One printer. Information regarding the
materials and tips that can be used by the printer is also included in this chapter.
Printer Overview
Main Components
This printer has been designed to allow easy access to the most frequently accessed areas on
the system. System components are highlighted in Figure 1 and described in Table 1.
Figure 1: System Components
Do not energize when the rear panel is not secured in place.
6
16
13
5
4
3
2
1
15
14
10
9
11
8
12
7
