Part Replacement Procedures Replacing the Resin Ingress Tube
Page 68
© Copyright 2022 Stratasys. All rights reserved.
8. Cut the two zip ties holding the resin ingress tube to the sensors, which are viewable from
the side panel, shown in Figure 18.
9. Disconnect the tube from the T-Connector shown in Figure 18 in a yellow box.
10. Plug the open resin ingress tube to prevent resin from spilling.
11. Disconnect the resin ingress tube from the midplate glass by reaching through the left
access panel.
12. Pull resin ingress tube through the grommet and remove it from the printer.
13. Before connecting the new resin ingress tube, take a clean dry wipe and apply IPA. Use
this wipe to clean any remaining resin on the connectors.
14. Remove the replacement resin ingress tube from the accessory tool kit.
15. Route the replacement resin ingress tube through the orange grommet.
16. Connect one side of the resin ingress tube to the midplate connector.
17. Route the resin ingress tube through resin ingress sensors.
18. Connect the resin ingress tube to the T-Connector.
19. Anchor the replacement resin ingress tube to both sensors with zip ties as shown in
Figure 18.
20. Ensure both ends of the resin ingress tube are fully seated into the connectors.
21. Reinstall the printer back panel and access panel door.
CAUTION:
Do not damage the sensors.
Warning: Skin contact hazard
Prolonged contact with solvents can cause skin irritation. Do not continue before
putting on protective gloves.
Do not spill any resin inside the printer. If any resin is spilled clean it immediately.
