4.4 Threading (Fig. 8a + b)
CAUTION! Danger of injury!
Before threading switch off electrically with the S0 main switch in
particular after the machine is stopped by the thread controller due
to thread breakage.
Otherwise there is a risk of injury by crushing and needle piercing.
The thread has to be threaded in through the thread eyelets according to Fig. 8a + b.
In the needle the thread is fed in from bottom to top into the eye of the needle.
4.5 Operating element in the distribution box
Fig. 9
