Strobel KA-ED - Setting stitch depth

24 BA_KA-ED_A22_190313_en.doc
4.8 Setting the stitch depth (Fig. 10 + Fig. 12a)
The stitch depth can be set very exactly by a control knob in the front beneath the
cavity. It is indicated optically by a three-digit display (Fig. 10).
Fig. 12
a)
b)
