4.7 Inserting the sewing material (Fig. 11 + Fig. 16b)
CAUTION! Danger of injury!
The operator should take sufficient care when sewing and keep an
eye on the sewing area. Otherwise there is a risk of injury by crushing
and needle piercing.
Before closing the pneumatic clamping device by pressing the START
button S4 both hands need to be withdrawn from the clamping
area.
The part to be padded should be inserted in such a way that the lower
part of the lapel lies towards the needle plate; the stitches run
from bottom to top on the lapel and from the front fold line towards the lapel tip (Fig.
11).
The first stitch comes in at about the point that lies along the reflective foil edge
during inserting.
There is a silver marking on the rear Differential feed. This mark identifies the point at
which the machine starts with sewing at the earliest (Fig. 16b). The red marking on the
bar after that marks the end of the sewing area.
Fig. 11
