4.11 Setting the stitch length (Fig. 12b)
The stitch length on the roll padder is 6.5 mm constant.
The stitch length setting on the machine head can be used to even out transport
differences when sewing material thicknesses are extreme.
As a rule:
thin to medium sewing material : stitch length 6 to 6.5
medium to thick sewing material : stitch length 6.5 to 7
Setting:
- Switch off main switch S0.
- Press stitch length setting button down and turn handwheel in the machine's
rotation direction (Fig. 12b) until the setting knob engages.
- Turn handwheel against the direction of rotation until the desired stitch length
value on the handwheel agrees with the yellow mark on the machine stand.
- Release the stitch length setting knob again.
IMPORTANT:
The installed return spring has to push the setting knob all the way
back out; the handwheel needs to be freely turnable in the running
direction.
