PPrroobblleemm PPoossssiibbllee CCaauussee SSoolluuttiioonn
No air is exiting the turn bladder Make sure that the LED (D27) is lit to
show the TLD solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the TLD inflate
solenoid
No back right inflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
Possible leak in the turn bladder Listen for air flowing into the turn
bladder
Look for a leak in the turn bladder
If you find a leak, replace the turn
bladder assembly
No air entering the turn bladder Make sure that the LED (D22) is lit to
show the BRI solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the BRI inflate
solenoid
No back right deflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
No air is exiting the turn bladder Make sure that the LED (D23) is lit to
show the BRD solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the BRD inflate
solenoid
PPrroobblleemm PPoossssiibbllee CCaauussee SSoolluuttiioonn
No back left inflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
Possible leak in the turn bladder Listen for air flowing into the turn
bladder
Look for a leak in the turn bladder
If you find a leak, replace the turn
bladder assembly
No air entering the turn bladder Make sure that the LED (D34) is lit to
show the BLI solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the BLI inflate
solenoid
No back left deflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
EN 22 2971-009-002 Rev D.0
