PPrroobblleemm PPoossssiibbllee CCaauussee SSoolluuttiioonn
No air is exiting the turn bladder Make sure that the LED (D36) is lit to
show the BLD solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the BLD inflate
solenoid
No seat right inflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
Possible leak in the turn bladder Listen for air flowing into the turn
bladder
Look for a leak in the turn bladder
If you find a leak, replace the turn
bladder assembly
No air entering the turn bladder Make sure that the LED (D25) is lit to
show the SRI solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the SRI inflate
solenoid
No seat right deflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
No air is exiting the turn bladder Make sure that the LED (D24) is lit to
show the SRD solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the SRD inflate
solenoid
PPrroobblleemm PPoossssiibbllee CCaauussee SSoolluuttiioonn
No seat left inflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
Possible leak in the turn bladder Listen for air flowing into the turn
bladder
Look for a leak in the turn bladder
If you find a leak, replace the turn
bladder assembly
No air entering the turn bladder Make sure that the LED (D33) is lit to
show the SLI solenoid is energizing
(see
Main power board assembly
(page 14))
If energized, replace the SLI inflate
solenoid
No seat left deflate Loose or disconnection of the pod
manifold connector
Make sure that the pod manifold
connector is set into the manifold and
secured
2971-009-002 Rev D.0 23 EN
