CCOOLLOORR DDEEFFIINNIITTIIOONN
Indicates the current procedure fluid volume captured after RESET selected (white)
Indicates canister fluid volume is FULL (yellow)
TTaabbllee 1177 –– MMeessssaaggee AArreeaa CCoolloorrss
CCOOLLOORR DDEEFFIINNIITTIIOONN
Indicates NOTIFICATION message (blue)
Indicates ERROR message (yellow)
TTaabbllee 1188 –– AAuuddiibbllee EEvveenntt IInnddiiccaattoorrss
EEVVEENNTT IINNDDIICCAATTIIOONN TTRRIIGGGGEERR
Button Touch Click tone
Main control panel display and
secondary control panel display
button actuation
Error
Three slow tones, three times
Any error message
Initial Startup
Chime tone
Startup screen with progress bar
Notification
Two declining tones Any notification message
Task Complete (confirmation) Ding tone Valid manifold installed successfully
TTaabbllee 1199 –– AAbbbbrreevviiaattiioonnss aanndd AAccrroonnyymmss
NNAAMMEE DDEEFFIINNIITTIIOONN
AC
Alternating Current
CA Canadian
DC Direct Current
HEPA
High Efficiency Particulate Air
IR
Infrared wavelength light
kPA
Kilopascal
L
Liter
MAX Maximum
MED Medium
MIN Minimum or Minutes
mL Milliliter
ML
Multilanguage
mm-Hg Millimeter of mercury
OR
Operating Room
