7. See
To Install Disposable Components
(page 37).
44..22.. TToo IInnssttaallll DDiissppoossaabbllee CCoommppoonneennttss
WWAARRNNIINNGG -- The manifold is for single patient use only. Do not reuse, process, service, modify, or repackage a single
use device.
• The single-use device may not withstand chemical, chemical vapor, or high temperature sterilization processing.
• Design features may make cleaning difficult.
• Reuse may create a contamination risk and compromise structural integrity, resulting in operational failure during use.
Failure to comply may lead to infection or cross-infection and result in patient and/or healthcare staff injury.
WWAARRNNIINNGG -- Before use, inspect each disposable component for damage. Do not use any equipment if damage is
apparent.
WWAARRNNIINNGG -- Do not use a manifold that has been dropped or mishandled. Failure to comply may cause leakage and
result in patient and/or healthcare staff injury.
FFiigguurree 2200 –– DDoo NNoott DDrroopp tthhee MMaanniiffoolldd
WWAARRNNIINNGG -- Do not remove the suction tubing from the manifold ports during use and at shutdown. Always leave the
suction tubing attached to the manifold ports after installation.
WWAARRNNIINNGG -- Do not use a Y-connector to add more than one suction line to each port. Failure to comply may cause
cross-contamination and result in patient injury.
FFiigguurree 2211 –– DDoo NNoott UUssee aa YY--ccoonnnneeccttoorr
NNoottee -- If the collection of small specimens is required during the procedure, select a specimen collection manifold with
a collection tray. Obtain additional specimen collection trays for use, if necessary. See
For Use With
(page 12).
NNoottee -- If specimen collection is not required during the procedure, select the disposable 4-port manifold.
700000969828 Rev-AA 37 EN
