55..33..11.. TToo IInnssttaallll tthhee FFlluuiidd SSuuccttiioonn HHEEPPAA FFiilltteerr
NNoottee -- Replace the filter REF 0702-034-000 every six months or as indicated on the control panel display of the rover.
Failure to comply will result in the reduction of fluid suction or an increase in odor.
NNoottee -- The filter life is 500 hours. The rover calculates filter usage time automatically. Always reset the filter timer after
the filter is replaced.
1. Make sure the rover power switch is OFF.
2. Turn the filter cover counterclockwise and align the arrow to unlock the filter cover. Remove the filter cover (Figure 41).
FFiigguurree 4411 –– RReemmoovvee aanndd RReeppllaaccee tthhee FFiilltteerr
3. Remove and properly dispose of the used HEPA filter.
4. Obtain a new HEPA filter. See
For Use With
(page 12).
5. Mark the replacement date on the label of the new HEPA filter.
6. Install the new HEPA filter into the filter compartment.
7. Install the filter cover over the filter compartment; turn the filter cover clockwise to align the arrow in the lock position.
55..33..22.. TToo VVeerriiffyy PPrrooppeerr FFiilltteerr IInnssttaallllaattiioonn
1. Connect the rover power cord to facility power.
2. Press the rover power switch to the ON position.
3. Read the safety information on the control panel display. Based on the configuration of the rover, select OK or
CONFIRM on the control panel.
4. Insert a manifold into the manifold receptacle.
5. Turn on suction and adjust the canister to the maximum suction level. Make sure the maximum suction level is obtained.
NNoottee -- If the maximum suction level is NOT reached, reposition the filter. If the suction level is still NOT reached,
contact service.
55..33..33.. TToo RReesseett tthhee FFiilltteerr TTiimmeerr
1. Access the SETTINGS menu. Select the PREFERENCES dialog and the FILTER button (Figure 9).
2. Touch the FILTER button to access the FILTER dialog and RESET HOURS button. Touch the button to reset the hours
to zero; close the dialog.
700000969828 Rev-AA 53 EN
