Stryker Operating Room Information System User Manual

30
S
• One (1) Extron MHR5 or equivalent (maximum 150')
• One (1) - Four (4) strand, multimode ber optic cable
º Quantity of bers within cable - Four (4)
º LC Connectors on each end
º 50/125 Micron
ITEM-ITEM QTY SIZE
3PR – A
1
1 1/4"
8.4.2 IBC Cable Specications
• One (1) Belden 8723 or equivalent (maximum 1000')
• One (1) Extron MHR5 or equivalent (maximum 150')
• One (1) Extron MHR5 or equivalent (maximum 150')
ITEM-ITEM QTY SIZE
IPR – ICW
1
1 1/4"
8.4.3 Level System Cable Specications
• One (1) Belden 8723 or equivalent (maximum 1000')
• One (1) Belden 8241 or equivalent (maximum 1000')
ITEM-ITEM QTY SIZE
LPR – S
1
1"
8.5 Bracket Mounted Wall /Ceiling Speaker
Conduit One (1) 3/4" conduit
Cabling • Cables provided by the Hospital/Contractor for runs over 50'
• Cables pulled by the Hospital/Contractor
• Leave a 15' (4.5m) service loop at each end for terminations
• Cable Specications:
º One (1) Belden 8723 or equivalent (maximum 1000')
Back Box • 4"W X 4"H junction box with single-gang mud ring.
• Mounted 12" (minimum) behind projector mounting bracket (wall mounted
only)
• Flush Mounted in ceiling (ceiling mounted only)
Power None
ITEM-ITEM QTY SIZE
3WS/3CS – A (SPI3)
1
3/4"
IWS/ICS – ICW (IBC)
1
3/4"
