5.2 Documentation Station (Hospital Provided)
Note All conduits should be provided with pullstrings and have minimum bends or
curves. All conduits have a maximum length of 45' (13.7m). Conduits must have
insulated bushings on all open ends.
e hospital-provided documentation station must allow for the physical dimensions and power re-
quirements for all equipment it is to hold.
CUSTOMER SUPPLIED DOCUMENTATION STATION (DOC4)
Power Recommend four (4) - 20 amp circuits
• One (1) circuit for quad outlet behind video router.
• One (1) circuit for quad outlet behind light PSB (if required).
• One (1) circuit for duplex outlet under touch panel.
• One (1) circuit for quad outlet behind digital capture device.
• All documentation station circuits require critical power.
Space Requirements Doc station must allow for a minimum 2" cable passage between all compo-
nents housed inside.
• Section housing video router must have an interior dimension of at
least 27.5"W x 31"H x 29"D.
• Section housing video router must be vented.
• Doc station must allow for direct access to backboxes per requirements
listed below.
Data Per listed equipment
Backbox Per listed equipment
Install two (2) Ethernet connections for the SORN (Stryker's Remote Device Management System) and
SDC, respectively. A telephone connection may be desired for a nurse's phone. Similarly, additional
Ethernet connections may be desired for a Nurses Computer and/or PACS Computer. If local Video
Conferencing via a CODEC is installed, an additional Ethernet connection is required. All additional
telephone/Ethernet connections will be specied by the Hospital.
5.3 Documentation Station Equipment Requirements
SWITCHPOINT INFINITY 3 (A1)
Dimensions • Media Router: 20.6"W x 24"H x 17"D
• Control Section: 12.5"W x 2.6"H x 17"D
• Total Space Required: 27.5"W x 31"H x 29"D
Data One (1) Ethernet connection
Back Box • One (1) 18"W x 18"H x 4"D (or larger) junction box ush mounted.
• Set bottom of box 9" above nished oor.
• Terminate all integration conduits to this junction box.
