Stryker ProCuity Series User Manual

To release SStteeeerr--LLoocckk, depress the red side of the pedal until the pedal is in the neutral position (Figure 9).
NNoottee -- To move in any direction, release the SStteeeerr--LLoocckk pedal.
FFiigguurree 88 –– AAppppllyyiinngg SStteeeerr--LLoocckk FFiigguurree 99 –– RReelleeaassiinngg SStteeeerr--LLoocckk//nneeuuttrraall ppoossiittiioonn
AAccttiivvaattiinngg tthhee CCPPRR rreelleeaassee hhaannddllee
CCAAUUTTIIOONN -- Always confirm that all persons and equipment are away from the area below and around the Fowler before
you activate the CPR release handle. The CPR release handle is for emergency use only.
When you raise the Fowler and need quick access to the patient, pull the CPR release handle to position the product to 0
degrees.
The two CPR release handles are on the left and right side of the litter Gatch section (A) (Figure 10).
To pull the CPR release handle:
1. Pull the handle (A) on the left or right side of the litter Gatch section (Figure 10).
NNoottee -- Release the CPR release handle at any time to stop product Fowler, Gatch, and foot section motion.
2. Guide the Fowler to the flat position.
3009-009-001 Rev B.0 19 EN

Stryker ProCuity Series Specifications

General

Bed Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Integrated Scale	Yes
Bed Exit System	Yes
Side Rail Controls	Yes
Category	Medical Equipment
Monitoring Parameters	Weight, bed exit
Display	Touchscreen
Alarms	Bed Exit, Low Battery
