Stryker ProCuity Series User Manual

AAcccceessssoorriieess aanndd ppaarrttss
These accessories and parts may be available for use with your product. Confirm availability for your configuration or
region.
NNaammee NNuummbbeerr
Battery
700000341245
Foot extender mattress assembly
300900670810
Two-stage IV pole, single
300900350100
Two-stage IV pole, dual
300900350200
Line management (pack of 70)
300900450010
Patient helper bracket
300900450100
ZZiimmmmeerr® patient helper bracket
300900450105
Pendant, basic
300900470100
Pendant, advanced
300900470200
Upright oxygen bottle holder (standard)
300900450050
Upright oxygen bottle holder (large)
300900450150
RRaaiissiinngg oorr lloowweerriinngg tthhee IIVV ppoollee ((ooppttiioonn))
CCAAUUTTIIOONN
• Do not load the IV pole above the safe working load of 17.6 lb (8 kg).
• Do not load an individual IV pole hook above the safe working load of 8.8 lb (4 kg).
• Do not use the IV pole as a push or pull device.
To position the IV pole:
1. Lift and pivot the IV pole from the storage position and push down until the IV pole locks into the receptacle.
2. To raise the height of the pole, pull up on the telescoping portion (A) of the pole until it locks into place at the fully raised
position (Figure 16).
3. Rotate the IV hangers (B) to the desired position and hang the IV bags (Figure 16).
4. To lower the pole, turn the latch (C) clockwise until the telescoping portion (A) lowers into the bottom tube (Figure 16).
5. Lift up and pivot the pole down into the storage position.
EN 38 3009-009-001 Rev B.0

Stryker ProCuity Series Specifications

General

Bed Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Integrated Scale	Yes
Bed Exit System	Yes
Side Rail Controls	Yes
Category	Medical Equipment
Monitoring Parameters	Weight, bed exit
Display	Touchscreen
Alarms	Bed Exit, Low Battery
