Stryker ProCuity Series User Manual

A
C
G
B
D
E
A
F
H
A Home
Returns to the HHoommee screen (
Footboard control panel -
Home
(page 29))
B Info
Displays the SSccaallee IInnffoo screen
C
Save weight
Select to save the current displayed weight (
Weighing a
patient
(page 33))
D
Zero (Non-NAWI)
Tare (NAWI)
Select to zero/tare the scale or set the scale for a new
patient (
Zeroing/taring the scale (page 32))
E
Add equip.
Select to add or remove equipment (
Adding or removing
equipment
(page 33))
Indicates how many items have been added to bed
F
Scale history
Displays the SSccaallee HHiissttoorryy screen
NNoottee -- The SSccaallee HHiissttoorryy stores up to 40 scale
readings.
G
Weight change indicator Displays an up or down arrow to indicate weight change
H Exit Returns to the SSccaallee screen
ZZeerrooiinngg//ttaarriinngg tthhee ssccaallee
Before you place a patient on the product, zero/tare the scale.
NNoottee
• ZZeerroo will display for non-NAWI and TTaarree will display for NAWI.
• Always zero/tare the scale after you add a support surface, mattress, or linens to the bed frame.
To zero/tare the scale:
1. Press the SSccaallee button (D) on the footboard control panel (
Footboard control panel - Home (page 29)).
2. On the SSccaallee screen, press the ZZeerroo//TTaarree button (D) (
Footboard control panel - Scale (page 31)).
3. On the NNeeww PPaattiieenntt?? screen, you may choose from the following:
• YYeess to zero/tare and delete scale history.
• NNoo to zero/tare and not delete scale history.
• CCaanncceell to cancel zero/tare and return to the SSccaallee screen.
NNoottee -- Do not touch the product when you zero/tare the scale.
EN 32 3009-009-001 Rev B.0
