pg 10
DIG - dual digital delay
Dual Delay Configuration Modes
Series
In Series configuration, Delay 2 (the rhythmic sub-delay) feeds Delay 1 in
the following manner:
Series configuration diagram
This is equivalent to putting two single delay pedals in succession on
your pedalboard� A mono input feeds both left and right channels�
Ping Pong
In Ping Pong mode, the delays are configured in a series “ping-pong”
structure�
Ping Pong configuration diagram
In stereo, each delay acts as a ping-pong delay, and they interact when
both MIX knobs are turned up� When using a mono output signal, this
configuration is the same as the Series configuration�
