pg 11
DIG - dual digital delay
Dual Delay Configuration Modes (cont�)
Parallel
In Parallel configuration, the delays do not interact with each other, but
produce their outputs “side-by-side�”
Parallel configuration diagram
In stereo, Delay 1 outputs to the left channel and Delay 2 outputs to the
right channel� When the right output is not used, the wet signal sums to
mono so that both parallel delays are heard from the left output�
