928 Mixing Console
E 3/2 Jumpers
Edition:
07.02.01
Remote control key With the START key the fader start can be prepared or initiated. If the
key is pressed when the fader is closed (dim backlight of the key) the
fader start command is executed as soon as the fader is opened and the
ON key is activated.
If the START key is pressed when the fader is already open and the ON
key is active, it immediately executes the fader start command.
J4
1-2 (default) START key is active
2-3, and
D18, D30 removed
START key is ineffective
J5
1-2 The START key generates start pulses
2-3 (default) The START key functions as a latching
start/stop key and enables or disables fader start
activation with the fader control
Signalization The 928 mixing console features two signaling busses that are used for
on-air signaling and deactivation of the studio speakers.
J11
2-3 (default) Fader start active (not applicable to version 2 of
the input unit)
J12
1-2 When the microphone channel is opened, the
CR monitor is dimmed (DJ mode)
2-3 (default) When the microphone channel is opened, the
studio speaker is switched off, and the studio
on-air lamp is activated if the ON AIR signal is
available or the STUDIO ON key in the signaling
unit is pressed.
J13
1-2 (default) The microphone input acts on the signaling
busses.
2-3 The LINE input acts on the signaling busses
Input channel Meters The built-in LED meter can be operated with VU or PPM characteristic
and can indicate either the input signal, the post-fader signal or the sig-
nal on the direct output (N-1).
J7
1-2 (default) PPM characteristic
2-3 VU characteristic
J8/J10
1-1 (default) Meter before equalizer
2-2 Meter on direct (N-1) output signal
3-3 Meter after fader
Direct output The signal for the direct output can optionally be tapped before or after
the fader.
J14
1-2 (default) Direct output post-fader
2-3 Direct output pre-fader
J9
1-2 For talkback to the Dir/N-1 output the normal
output signal is interrupted (TB signal exclusive)
2-3 (default) The talkback signal is added to the Dir/N-1 signal
