35
① Module Selection
Single press the left right selection button, to choose FX module:（Modul1-Modul2-Delay1-
Delay2-Reverb1- Reverb2-GEQ1-GEQ2）。
② Typ e
Single press the dropdown button, then choose a delay type from the dropdown list—One
Echo 1/4，Two Echo 1/8，Three Echo 1/16，Three Echo 1/16 Delayed，Four Echo
1/16，One Echo 1/4 with 4 Reflect.
③ Dry-Wet
Ranges from 0 to 100 with a default @ 0. Adjust the parameter of Dry-Wet by dragging the
slider, or turning the main encoder on the control panel.
④ EQ LS
Curve chart: displays the LS curve
Gain：ranges is ±18 dB, with a default @ 0 dB. Adjust the Gain by turning the main encoder
or on the touch screen (fine tuning can be activated by pressing the main encoder knob).
Double press the parameter frame to set it as default.
Freq：ranges from 20 Hz to 200 Hz, with a default @ 100 Hz. Adjust the Frequency by
turning the main encoder or on the touch screen (fine tuning can be activated by pressing
the main encoder knob). Double press the parameter frame to set it as default.
⑤ EQ HS
Curve chart: displays the HS curve
Gain：ranges is ±18 dB, with a default @ 0 dB. Adjust the Gain by turning the main encoder
1 2
3 4 5
6
