digiLiVE 4C/8C SPECIFICATIONS
Input Characteristics
Output impedance of signal generator:150Ω
Input Input Impedance Connector Maximum Input Sensitivity Range
MIC INPUT 1.5KΩ XLR
(Balanced)
+16 dBu 0 to
+60dBu
60dB
LINE INPUT 10KΩ TRS(Balanced) +30 dBu -20 to
+40dBu
ST INPUT 10KΩ TRS(Balanced) +22dBu -20 to
+20dBu
40dB
Output Characteristics
Output Output Impedance Connector Residual Output
Noise
Maximum Output
BUS OUT 470Ω XLR (Balanced) -90 dBu +18 dBu
PHONES
OUT
100Ω TRS(Unbalanced) -92 dBu +22 dBu
Frequency Response
Fs= 48 kHz @20 Hz–20 kHz, referenced to the nominal output level @1 kHz
Input Output RL Conditions Min TYP Max Unit
MIC INPUT BUS 600Ω 0dBu @20 Hz–20 kHz, GAIN: 0dB -0.2 0 0.1 dB
ST INPUT -0.2 0 0.1
Total Harmonic Distortion
Fs= 48 kHz @ Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
Input Output RL Conditions Min TYP M
ax
Unit
MIC INPUT BUS 600Ω 0dBu @20 Hz–20 kHz, GAIN: 0dB 0.008
%
ST INPUT 0.005
Hum & Noise
Fs= 48 kHz, EIN= Equivalent Input Noise@ 20Hz–20kHz
Input Output RL Conditions Min TYP Max Unit
INPUT 1-2
(digiLiVE 4C)
INPUT 1-6
(digiLiVE 8C)
BUS 600Ω
Rs= 150Ω, GAIN: Max. Master fader
at nominal level and one Ch fader at
nominal level.
-126
EIN
dBu
-70
Rs= 150Ω, GAIN: Min. Master fader
at nominal level and one Ch fader at
nominal level.
-88
All INPUT
Rs= 150Ω, GAIN: Min. Master fader
at nominal level and all channel
faders at nominal level.
-78
Residual Output Noise, BUS Master
Off
-90
Hum & Noise are measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite
dB/octave attenuation.
