Input Function
Function Parameter
Phase Normal/Reverse
Delay 0 msec to 200 msec
FX (Effects) 2Reverb / 2Delay
Gate
Threshold= –80dB to 0dB
Attack=0.5msec to 100 msec
Release=2msec to 2sec
Hold=2msec to 2sec
Depth= –80dB to 0dB
Threshold= –80dB to 0dB
Compressor
Attack=0.5msec to 100 msec
Release=2msec to 5sec
Gain= –12 dB to +12dB
Output Function
Function Parameter
Delay 0 msec to 200 msec
Insert 1GEQ
L-R Pan CSR= 0% to 100%
Fader Level:–80dB to +10 dB
LISTEN On/Off
MUTE On/Off
Oscillator Type: White noise/ Sine
wave/ Pink noise
Level: –76dB to 0dB
Frequency= 10 Hz to 20
kHz
MONITOR/PHONES Level: –76dB to 0dB
Specifications
Maximum Voltage Gain 80 dB INPUT to BUS OUT
Sampling Frequency 48kHz
Internal Processing 40-bit floating point
Latency <1.8msec, any input to any output
Phantom Power 48V, individually switchable per channel
Crosstalk (@1kHz) -85dB Adjacent Input Channels (INPUT, ST IN, to BUS OUT)
GAIN: 0dB
Fader Rotary Encoder x 3
Dimensions
Net Weight
Power Requirements
