STULZUltraSonic-SystemforDirectRoomHumidicationBNB-  Installation
7.4.2.1. Overview connection
Proceedasfollowstoconnecttheoverow:
3
Connect the other end of the hose to the
local waste water system.
2
Useacliptoxthehoseinplace.
1
Pushadrainagehose(insidediameter15
mm)overtheoverowtting.
Overowpipe1/2",providedonsite
Overowpipe1/2",providedonsite
Overowpipe1/2",providedonsite
CAUTION
Using a safety tray.
Ifthehumidierismountedonawall,theoverowpipemustbeconnectedforadditionalsafety.How-
ever,nowaterowsintotheoverowduringnormaloperation.Ifitisnotpossibletoconnectthe
safetyoverowtothedrain,installthehumidierinthesafetytray.(Seesection"7.3.Wall-mounted
installation"onpage37).
Note
CAUTION
Free over ow.
Theoverowmustnotbeclosedwhiletheunitisinoperation.
