7.4.4 Signals
PID-3519-INPUTSIGNALS v6
Table 116: LOVPTUV Input signals
Name
Type Default Description
U3P GROUP
SIGNAL
- Voltage connection
BLOCK BOOLEAN 0 Block the all outputs
CBOPEN BOOLEAN 0 Circuit breaker open
VTSU BOOLEAN 0 Block from voltage circuit supervision
PID-3519-OUTPUTSIGNALS v6
Table 117: LOVPTUV Output signals
Name Type Description
TRIP BOOLEAN Trip signal
START BOOLEAN Start signal
7.4.5 Settings
PID-3519-SETTINGS v6
Table 118: LOVPTUV Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
UPE 1 - 100 %UB 1 70 Operate voltage in % of base voltage
UBase
tTrip 0.000 - 60.000 s 0.001 7.000 Operate time delay
Table 119: LOVPTUV Group settings (advanced)
Name
Values (Range) Unit Step Default Description
tPulse 0.050 - 60.000 s 0.001 0.150 Duration of TRIP pulse
tBlock 0.000 - 60.000 s 0.001 5.000 Time delay to block when all 3ph
voltages are not low
tRestore 0.000 - 60.000 s 0.001 3.000 Time delay for enable the function after
restoration
Table 120: LOVPTUV Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 12 - 1 1 Selection of one of the Global Base
Value groups
1MRK 505 384-UEN A Section 7
Voltage protection
Breaker protection REQ650 2.2 IEC 199
Technical manual
